Autoflame Gas and Air Pressure Sensors

Gas pressure sensors can be used for the following purposes:

  • Gas Valves Proving System (VPS) and/or gas pressure limits when used with an MM system.
  • Gas pressure limits only when used with an MM system.

Air pressure sensors can be used for the following purposes:

  • Combustion air pressure proving when used with an MM system.
  • Draft pressure control when used with the Mk8 MM.

The gas and air pressure sensors can also be used for gas / air pressure monitoring application when used with the Mk8 DTI.

Specifications :

  • IP Rating : 65
  • NEMA Rating : 4
  • Check Type : Self-check
  • Max. & Min Operating Temperature : 85°C (185°F) to -25°C (-13°F)
  • Pressure measuring port : ¼” parallel NPT / BSP female
  • Differential pressure port : 1/8” parallel NPT / BSP female
Gas Pressure Sensors Type : Air Pressure Sensors Type :
MM80006MM80005
MM80008MM80013
MM80011
MM80012
MM80014



ATEX Certified Gas / Air Pressure Sensor for use in Hazardous Environments application where Explosion Proof equipment is required.

Gas Pressure Sensors Type : Air Pressure Sensors Type :
MM80006/EXP MM80005/EXP
MM80008/EXP MM80013/EXP
MM80011/EXP
MM80012/EXP
MM80014/EXP



* For any order enquiries, please consult JATI
