Autoflame Gas Control Valves – Flanged 50mm
Autoflame Flanged Gas Control valves are available in PN16 or ANSI flange type. They are also available in Stainless Steel or Aluminium body construction as standard. These valves require large servomotor (25Nm torque)
- Valve body manufactured from Aluminium.
- Butterfly disc and drive shaft manufactured from 316 stainless steel as standard.
- Other materials available on request.
- Large Positioning Motor Required
- Mating Flanges, Rubber Gaskets & Bolts are not supplied unless specified on order.
Specification :
| Part No. | KG’s | Description |
| GVF45028/30 | 9 | PN16 50mm (2″) |
| GVF46526/30 | 9 | PN16 65mm (2.5″) |
| GVF48027/30 | 10 | PN16 80mm (3″) |
| GVF410026/30 | 11 | PN16 100mm (4″) |
| GVF12527/30 | 12 | PN16 125mm (5″) |
| GVF415028/30 | 13 | PN16 150mm (6″) |
* For any order enquiries, please consult JATI
