DUNGS Double Solenoid Valve DMV-D / DLE…/11 eco Series
The DUNGS double solenoid valve DMV integrates two solenoid valves in one compact fitting.
Double solenoid valves are used where two single valves were mounted previously.
In connection with DUNGS gas regulators and additional components, a wide variety of regulating tasks can be performed. It does not contain any non-ferrous metals, suitable for gases of up to max. 0.1 vol.% H2 S, dry.
Suitable for gases of families 1, 2, 3 and other neutral gaseous media.
- Automatic shut-off valves as per DIN EN 161 Class A Group 2.
- Two A valves in one housing
- Double seat valves
- High flow rates
- Max. operating pressure up to 500mbar (50 kPa)
- Fast closing
- Fast opening (DMV/11 eco, DMV-D/11 eco)
- Adjustable main volume (DMV-D/11 eco, DMV-DLE/11 eco)
- DC solenoid
- Low electric power consumption through power switching
- Mountable closed position signal contact
- Compact, light-weight
| Type | Connection DN | Solenoid No. | Switching Rate/h |
| DMV 525/11 eco | Rp 2 (DN 50) | 1411/2P | 60 |
| DMV 5065/11 eco | DN 65 | 1411/2P | 60 |
| DMV 5080/11 eco | DN 80 | 1511/2P | 60 |
| DMV 5100/11 eco | DN 100 | 1611/2P | 60 |
| DMV 5125/11 eco | DN 125 | 1711/2P | 60 |
| DMV-D 525/11 eco | Rp 2 (DN 50) | 1411/2P | 60 |
| DMV-D 5065/11 eco | DN 65 | 1411/2P | 60 |
| DMV-D 5080/11 eco | DN 80 | 1511/2P | 60 |
| DMV-D 5100/11 eco | DN 100 | 1611/2P | 60 |
| DMV-D 5125/11 eco | DN 125 | 1711/2P | 60 |
| DMV-DLE 525/11 eco | Rp 2 (DN 50) | 1411/2PL | 20 |
| DMV-DLE 5065/11 eco | DN 65 | 1411/2PL | 20 |
| DMV-DLE 5080/11 eco | DN 80 | 1511/2PL | 20 |
| DMV-DLE 5100/11 eco | DN 100 | 1611/2PL | 20 |
| DMV-DLE 5125/11 eco | DN 125 | 1711/2PL | 20 |
* * For other configurations and spare parts, please consult JATI
