DUNGS Double Solenoid Valve DMV-D / DLE…/11 Series
The DUNGS double solenoid valve DMV integrates two solenoid valves in one compact fitting.
Double solenoid valves are used where two single valve were mounted previously.
In connection with DUNGS gas regulators and additional components, a wide variety of regulating tasks can be performed.
It does not contain any non-ferrous metals, suitable for gases of up to max. 0.1 vol.% H2 S, dry.
Suitable for gases of families 1, 2, 3 and other neutral gaseous media.
- Automatic shut-off valves as per DIN EN 161 Class A Group 2
- Two A valves in one housing
- Double seat valves – High flow rates
- Max. operating pressure up to 500 mbar (50 kPa)
- Fast closing
- Fast opening (DMV-D/11) or slow opening (DMV-DLE/11) with adjustable fast stroke for start gas volume
- Adjustable main volume
- DC solenoid
- Mountable closed position signal contact
- Threaded flange
- Compact, light-weight
| DMV-D (DLE) Type | Connection DN |
| DMV-D 503/11 | Rp 3/8 |
| DMV-D 507/11 | Rp 3/4 |
| DMV-D 512/11 | Rp 1 1/4 |
| DMV-D 520/11 | Rp 1 – Rp 2 |
| DMV-D 525/11 | Rp 2 |
| DMV-DLE 503/11 | Rp 3/8 |
| DMV-DLE 507/11 | Rp 3/4 |
| DMV-DLE 512/11 | Rp 1 1/4 |
| DMV-DLE 520/11 | Rp 1 – Rp 2 |
| DMV-DLE 525/11 | Rp 2 |
| DMV.. /11 Model Type | Flange with pipe thread Connection | |
| DMV 503/11 | Rp 3/8 | – |
| DMV 503/11 | Rp 1/2 | – |
| DMV 507/11 | Rp 1/2 | NPT 1/2 |
| DMV 507/11 | Rp 3/4 | NPT 3/4 |
| DMV 507/11 | Rp 1 | NPT 1 |
| DMV 512/11 – 520/11 | Rp 1 | NPT 1 |
| DMV 512/11 – 520/11 | Rp 1 1/4 | NPT 1 1/4 |
| DMV 512/11 – 520/11 | Rp 1 1/2 | NPT 1 1/2 |
| DMV 512/11 – 520/11 | Rp 2 | NPT 2 |
| DMV 525/11 | Rp 2 | NPT 2 |
* * For other configurations and spare parts, please consult JATI
